Specifications

• Mfr Part Number: PS-ADPT90W
• Input voltage: 100Vdc to 240Vdc
• Variation Range: 90-264Vac
• Input Current: 1.6A(MAX)
• Inrush current: 120 Amps Max. Cold start at 240Vac input, with rated load and 25 °C ambient
• Ac Leakage Current: 0.25mA Max. At 240Vac input
• Out Voltage: 19Vdc
• Out Current: 4.74A
• Tolerance: 5%(18.05~19.95 V)
• Ripple and Noise: 400mVp-p(MAX)
• Temperature Coefficient: ±0.05%/°C
• MTBF: 50000 hours at 25°C (MIL-STD-217F)
• Efficiency: 80%
• Short Circuit Protection: Yes
• Over current Protection: Yes
• Over Voltage Protection: Yes
• DC Wirings: UL1185 ,18AWG, Black L=1.5m
• Compatibility: Compatible with most 19V Input Notebooks include ACER TOSHIBA DELTA LITEON HP/COMPAQ LENOVO/IBM FUJITSU GATEWAY LISHIN ...etc
  • 4.8x1.7mm Compatibility: HP, Compaq, NEC, Asus
  • 5.5x1.5mm Compatibility: Acer Liteon Delta
  • 5.5x2.1mm Compatibility: HP, Compaq, Acer, Gateway, IBM, Asus, Liteon, NEC
  • 5.5x2.5mm Compatibility: HP, Compaq, Acer, Gateway, IBM, Asus, Liteon, NEC
  • 5.5x3.8mm Compatibility: Samsung
  • 6.3x3.0mm Compatibility: Toshiba, NEC
  • 6.5x4.5mm Compatibility: Sony Fujitu
  • 7.4x5.0mm Compatibility: HP Dell
