Specifications

• Mfr Part Number: WU334
• Display Technology: Single 0.48 DMD S410, DC3 chip DLP Technology by Texas Instruments
• Resolution: WUXGA (1920 x 1200)
• Maximum Resolution: WUXGA (1920x1200)
• Brightness: 3600 ANSI Lumens
• Contrast Ratio: 20,000:1
• Throw Ratio: 1.47 - 1.62
• Zoom Type: 1.1x optical, 0.8 - 2.0x digital
• I/O Connectors: 2x HDMI (with MHL), VGA-in, composite, audio-in, audio out, USB power, RS-232C
• Audio: 10W
• Keystone Correction: ± 40° Vertical
• Aspect Ratio: 16:10
• Offset: 116%±5%
• Projection Screen Size: 29" - 300"
• Projection Distance: 3.2' - 35.29" (no zoom)
• Projection Lens: F=2.10 ~2.31, f=15.59 ~ 17.14 mm manual
• Projection method: Front, rear, ceiling count, table top
• Uniformity: 70%
• Computer Compatibility: FHD, HD, WXGA, UXGA, SXGA, XGA, SVGA, VGA, Mac
• Video Compatiblity: PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p)
• Horizontal Scan Rate: 25 - 85 Hz (120 Hz for 3D)
• Vertical Scan Rate: 15 - 91 kHz
• Displayable Colors: 1.07 Billion
• Noise Level: 27 / 32 dB
• Power Supply: AC input 100-240 V, 50-60 Hz, auto-switching
• Power Consumption: 300W Typical (Bright mode), 330W Max (Bright mode), 210W Typical (Eco+ mode), 230W Max (Eco+ mode)
• Lamp Type: 240W
• Lamp life (Extreme Dimming/ Dynamic/ECO/Bright): 15,000/12,000/10,000/3,500
• Operating Temperature: 41 “104°F (5 “40°C), 85% max humidity
• Security: Security bar, Kensington lock, password protection
• On-Screen Display: Complete on-screen menu adjustment in 26 languages
• Remote Control: Full size remote
• Standard Accessories: AC power cord, remote control, carrying case, batteries for remote, multilingual CD-ROM user ™s manual, quick start card, and warranty card
• Optional Accessories: Universal ceiling mount, DLP Link 3D glasses, lamp, remote
• Optional Wireless: No
• Dimensions (WxDxH): 12.44 x 4.27 x 9.20 inch
• Weight: 6.75 lbs
• RoHS Compliant
