Specifications

• Mfr Part Number: WU336
• Display Technology: Single 0.48" DMD S410, DC3 chip DLP Technology by Texas Instruments
• Resolution: WUXGA 1920 x 1200
• Brightness: 3400 ANSI Lumens
• Contrast Ratio: 20,000:1
• Throw Ratio: 1.58 - 2.06
• Zoom Type: Digital 0.8-2.0x
• I/O Connectors: 2x HDMI (with MHL), VGA-in, composite, audio-in, audio out, USB power, RJ-45, RS-232C
• Audio: 10W
• Keystone Correction: ± 40° Vertical
• Aspect Ratio: 4:3, 16:9
• Offset: 116%±5%
• Projection Screen Size: 27" - 299"
• Projection Distance: 3.9' - 33.46"
• Projection Lens: F=2.43 ~2.78, f=16.91 ~ 21.60mm manual
• Uniformity: 70%
• Maximum Resolution: WUXGA (1920x1200)
• Computer Compatibility: FHD, HD, WXGA, UXGA, SXGA, XGA, SVGA, VGA, Mac
• Video Compatibility: PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p)
• 3D Compatibility:
  • Side-by-Side: 1080i50 / 60, 720p50 / 60
  • Frame-pack: WUXGA24, 720p50 / 60
  • Over-Under: WUXGA24, 720p50 / 60
• Horizontal Scan Rate: 25 - 85Hz (120Hz for 3D)
• Vertical Scan Rate: 15 - 91kHz
• Displayable Colors: 1.07 Billion
• Noise Level (Eco mode): 27/32db
• Power Supply: AC input 100-240V, 50-60Hz, auto-switching
• Power Consumption: 300W Typical (Bright mode), 330W Max (Bright mode), 210W Typical (Eco+ mode), 230W Max (Eco+ mode)
• Lamp Type: 240W
• Operating Temperature: Operating temp @ sea level up to 10000 feet = 23F (max); must manually switch to high altitude mode @ 5000 feet & above (using OSD)
• Security: Security bar, Kensington lock, password protection
• Remote Control: Full size remote
• Standard Accessories: AC power cord, remote control, carrying case, batteries for remote, multilingual CD-ROM user's manual, quick start card, and warranty card
• Optional Accessories: Universal ceiling mount, DLP Link 3D glasses, lamp, remote
• Optional Wireless: No
• Color Wheel: RYGCWB
• Projection method: Front, rear, ceiling mount, table top
• Dimensions (WxDxH): 12.44 x 4.27 x 9.20 inch
• Weight: 6.7 lbs / 3.06 kg
• RoHS Compliant
