Specifications

• Mfr Part Number: AOC-SAS2LP-MV8
• Features:
  • 8-channel SAS/SATA adapter with 600MB/s per channel
  • JBOD mode only, No RAID support
  • Affordable, easy-install, eight-port SAS/SATA Card
• Key Application: Storage arrays for Network Attached; Storage (NAS) and Nearline Backup
• Device Support: Up to 8x SAS/SATA disk drives, activity LED indicated for each drive (LED cables not included)
• Data Transfer Rates: Up to 6.0 GB/s per port
• RAID: No
• Bus Type: PCI-Express 2.0 x8
• Internal Connectors: 2x SFF 8087 connectors
• Supported Operating Systems
  • Windows 2003, 2008 and Vista
  • RedHat Enterprise Linux
  • Fedora Linux 9
  • SuSE Linux Enterprise
  • CentOS
• Dimensions (WxL): 2.7 x 6.6 inch
