Specifications

• Mfr Part Number: SYS-5039D-I
• Motherboard: Super X11SSL-F
• Processor: LGA1151
  • Supports Intel Xeon E3-1200 v5 Series Processors
  • CPU TDP up to 80W
• Chipset: Intel C232
• Memory: 4x 288pin DDR4-2133/ 1866/ 1600 DIMM Slots, ECC, Unbuffered, Max Capacity of 64GB
• Slots: 1x PCI-Express 3.0 x16 Slot (runs at x8), 2x PCI-Express 3.0 x8 Slots (one runs at x4)
• SATA: 6x SATA3 Ports, via Intel C232, Support RAID 0, 1, 5, 10
• Video: ASPEED AST2400 BMC Graphics
• LAN: Dual Intel i210AT Gigabit Ethernet Controllers
• Drive Bays: 4x 3.5" Internal Fixed Drive Bays (Enterprise SATA HDD only recommended), 2x 5.25" External Drive Bays
• Ports: 5x USB 3.0 Ports (2 rear, 2 via headers, 1 Type A), 6x USB 2.0 Ports (2 rear, 4 via headers), 1x VGA Port, 1x Serial Port (rear), 2x RJ45 LAN Ports,  1x RJ45 Dedicated IPMI LAN Port
• Form Factor: Mid-Tower
• Power Supply: 300W 80 PLUS Bronze Certified AC Power Supply w/ PFC
• System Cooling: 1x 90mm Rear PWM Fan w/ Tool-less Design
• Front Panel:
  • Buttons: Power On/Off
  • LEDs: Power, Hard Drive Activity, Network Activity, System Overheat
  • Ports: 2x Front Side USB Ports
• Color: Black
• Dimension (WxDxH): 7.25 x 16.75 x 14.25 inch / 184.0 x 425.0 x 362.0 mm
• Gross Weight: 40.0 lbs / 18.1 kg
• RoHS Compliant
