Specification

• Mfr Part Number: NVR1218

• Hardware:
  • Maximum Channel Number: 12 (including 4 Free License)

  • CPU: Embedded NVR SoC (1.0 GHz, Dual Core)

  • Memory: 1GB DDR3

  • Drive Bays: 2x 3.5" SATA HDD
  • Max Internal Raw Capacity: 20 TB (10 TB drive x 2) (Capacity may vary by RAID type)

  • External Interface: 1x USB 3.0 Port, 2x USB 2.0 Ports, 1x eSATA Port, 1x COM Port, 1x HDMI Port, 2x 3.5mm Audio Jacks (input/output)

  • LAN: 1x RJ-45 1GbE LAN Port

  • Wake on LAN/WAN

  • Fan: 1x (80 x 80mm) Fans

  • Power Recovery

  • Noise Level: 19.0 dB(A)

  • Scheduled Power On/Off

  • Power Supply Unit/Adapter: 60W

  • AC Input Power Voltage: 100 ~ 240V AC
  • Power Frequency: 50/60Hz, Single Phase

• Networking Protocols: CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN)

• Security: FTP over SSL/TLS, IP Auto-Block, Firewall, Encrypted Network Backup over Rsync, HTTPS Connection

• File System:
  • Internal Drives: EXT4

  • External Drives: EXT4, EXT3, FAT, NTFS, HFS+ (Read Only, with max. volume size 2TB)

• System Management:
  • Maximum Local User Accounts: 1024

  • Maximum Local Groups: 256

  • Maximum shared folder: 256

  • Windows Access Control List (ACL) Integration

• Utilities: Synology Assistant

• Management:
  • Auto DSM Upgrade

  • Push Notification - Mobile Devices

  • Email/SMS Notification

  • Customized User Quota

  • Customized Administrator/User Group

  • Syslog Support
  • DDNS Support

  • IPv6 Support

  • VLAN Support

  • PPPoE

  • Resource Monitor
  • Connection Manager

  • UPS Management

  • Scheduled Power On/Off
  • Custom Management UI HTTP/HTTPS Ports

• Application:
  • iOS/Android Application: DS File, DS Finder, DS Cam

  • File Station, VPN Server, Storage Analyzer, Hyper Backup

• Supported Clients: Windows 7 and 10, Mac OS X 10.11 onwards

• Power Consumption: 13.64 W (Access); 4.32 W (HDD Hibernation)

• Certifications: FCC Class B, CE Class B, BSMI Class B

• Dimensions (WxDxH): 100.0 x 225.5 x 165.0 mm

• Weight: 0.9 kg

• Package Contents: Main Unit, Accessory Pack, AC Power Adapter, AC Power Cord, RJ-45 LAN Cable, Quick Installation Guide, HDD bracket, USB installation dongle
