Specifications

• Mfr Part Number: NP-UM330XI-WK
• Optical:
  • Display Technology: 0.63" LCD w/ MLA
  • Resolution:
    • Native: XGA 1024 x 768
    • Maximum: UXGA 1600 x 1200
  • Light Output (Lumens): 3300 Lumens
  • Contrast Ratio (up to): 3000:1
  • Lamp Type: 265W AC
  • Lamp Life (up to): 3000 hours (normal) / 6000 hours (eco)
  • Screen Size (diagonal): 61.5 ~ 116.6 inch / 1.60 ~ 2.96 m
  • Throw Ratio: 0.36 ~ 1
  • Projection Distance: 1.47 ~ 2.8 ft / 0.45 ~ 0.85 m
  • Projector Angle: 53.1°
  • Lens:
    • Zoom: 1.0 ~ 1.4
    • Focus: Manual
    • F-number, f-number: F= 1.80mm
  • Keystone Correction: Automatic or Manual ±10°
• Signal Compatiblity/Connectivity:
  • Scan Rate:
    • Horizontal: 15 ~100 kHz
    • Vertical: 50~120 Hz
  • Supported Video Standards: NTSC, NTSC4.43, PAL, PAL-M, PAL-N, PAL 60, SECAM
  • SD/HD Video Signal Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
  • PC Signal Compatibility: VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA
  • Macintosh Compatibility: Yes
  • Input/Output Terminals:
    • RGB1(Analog): VGA 15-pin D-sub, Component Video Using ADP-CV 1E
    • RGB3(Digital): HDMI
    • Video 1: RCA
    • Video 2: S-Video
    • Audio 1: 1/8 inch stereo
    • Monitor Out:  VGA 15-pin D-sub
    • Audio Out: Yes (variable)
  • Audio: 16W Speaker
  • External Control: RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN (optional)
  • Sync Compatibility: Separate Sync/ Composite Sync/ Sync on G
  • Networking: RJ-45 Monitoring
• Electrical:
  • Power Requirements: 100~240V AC, 50/60 Hz
  • Input Current: 4.0A / 2.0A
  • Power Consumption (Normal/ ECO Mode/ Standby/ Standby Power Saving): 344W/ 233W/ 8W/ 0.2W
• Installation Orientation: Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
• Fan Noise: 35 dB (normal) / 28 dB (eco)
• Regulations: USA UL 60950-1 FCC Class B, C-UL CSA 60950-1 ICES-003 Class B
• Dimensions (WxDxH): 26.0 x 22.0 x 20.0 inch / 660.0 x 559.0 x 508.0 mm
• Weight: 49.0 lbs / 22.2 kg
