Specifications

• Mfr Part Number: SMT3000RM2UNC
• Output:
  • Power Capacity: 2700 Watts / 2880 VA
  • Max Configurable Power: 2700 Watts / 2880 VA
  • Nominal Output Voltage: 120V
  • Output Voltage Distortion: Less than 5%
  • Output Frequency (sync to mains): 50/60Hz ± 3Hz
  • Topology: Line Interactive
  • Waveform Type: Sine Wave
• Input:
  • Nominal Input Voltage: 120V
  • Input Frequency: 50/60 Hz ± 3 Hz (auto sensing)
  • Input Voltage Range for Main Operation: 82 - 144V
• Batteries & Runtime:
  • Battery Type: Maintenance-free Sealed Lead-Acid Battery with Suspended Electrolyte - leakproof
  • Typical Recharge Time: 3 hours
  • Replacement Battery:RBC43
  • RBC Quality: 1
• Communications & Management:
  • Interface Port: RJ-45 Serial, Smart-Slot, USB
  • Control Panel:
    • LED Status Display w/ On Line - On
    • Battery - Replace Battery and Overload Indicators, Multi-function LCD Status, Control Console
  • Audible Alarm:
    • Alarm When On Battery - Distinctive
    • Low Battery Alarm - Configurable Delays
• Surge Protection & Filtering:
  • Surge Energy Rating: 459 Joules
• Approvals: CSA, FCC Part 15 Class A, UL 1778
• Color: Black
• Maximum Height : 3.39inches (86MM, 8.6CM)
• Maximum Width :18.9inches (480MM, 48.0CM)
• Maximum Depth : 26.89inches (683MM, 68.3CM)
• Net Weight: 97.42lbs. (44.28KG)
