Specifications

• Mfr Part Number: BK013
• Features:
  • Very high cooling benchmarks complement its high cooling capacity of 180W TDP
  • Four high-performance 8mm heatpipes carry heat to optimal location on the cooling fins
  • Turbulence-reducing wave design on cooling fins reduces noise generation from airflow
  • Optimized 120mm be quiet! fan with PWM function supports the best balance of cooling performance and quiet operation
  • Even at 100% PWM function, noise is at scant 25.4dB(A)
  • Square, single tower design saves space and supports four-directional fan mounting for best heat convection
  • Compatibility with all current Intel and AMDTM sockets
  • Freely-selectable fan mount point is recommended for AMDTusers
  • Product conception, design and quality control in Germany
  • Top cover with brushed aluminum finish
• Socket Type:
  • Intel: LGA 775 / 1150 / 1151 / 1155 / 1156 / 1366 / 2011(-3) Suqare ILM / 2066

  • AMD: Socket 754 / 939 / 940 / AM2(+) / AM3(+) / AM4 / FM1 / FM2(+)

• Fan:
  • Model: Pure Wings 2 PWM 120mm
  • Speed: 1600 RPM
  • Noise Level: 50% RPM - 15.3 dBA, 75% RPM - 19.8 dBA, 100% RPM - 25.4 dBA
  • Air Flow: 51.0 CFM / 87.0 m3/h
  • Air Pressure: 1.4 mm H2O
  • Rated Voltage: 12 V

  • Input Current: 0.24 A

  • Input Power: 2.88 W

  • Bearing Type: Rifle
  • Motor: 4-pole Fan Motor
  • Connector: 4 Pin PWM
  • Cable Length: 220 mm

  • Life Expectancy: 80,000 hours @ 25°C
  • Dimensions: 120.0 x 120.0 x 25.0 mm
• Heatsink:
  • Heat Pipes Number / Diameter: 4x 8 mm
  • Material: Copper Base / Aluminum Fins
  • Number of Fins: 51
  • CPU Contact Surface: CNC machined
  • Dimensions : 122.0 x 122.0 x 160.0 mm
• Thermal Design Power: 180 W
• Dimensions (WxLxH): 122.0 x 147.0 x 160.0 mm (Overall)(w/o mounting material)
• Weight: 1.12 kg
