Specifications

• Mfr Part Number: CM-32

• Features:
  • Save on monthly rental fees with speedy cable internet and Wifi in one box

  • Work with U.S. cable Internet providers including Comcast XFINITY, Spectrum (Legacy Time Warner Cable and legacy Charter) and more

  • CableLabs certified 32 x 8 channel bonding for up to 1.3 Gbps cable download speed

  • AC2600 Wifi for faster speeds than typical ISP-provided combo boxes

  • Four-transmit, four-receive antenna design and AiRadar beamforming deliver farther coverage

  • Quick and intuitive setup with unique network ID and password

  • Fully-featured ASUSWRT makes Wifi setup and management straightforward

• Network: IEEE 802.11a/b/g/n/ac, IPv4, IPv6

• Modem: 32 x 8 CableLabs DOCSIS 3.0 certified

• Product Segment: AC2600 ultimate AC performance - 800+1734 Mbps

• Coverage: Very Large homes

• Data Rate: 802.11ac - up to 1734 Mbps

• Antenna: 4x External antenna

• Transmit/Receive:
  • MIMO technology

  • 2.4 GHz 4 x 4

  • 5 GHz 4 x 4

• Processor: Intel 1.6GHz combined processor

• Memory: 256 MB Flash, 512 MB RAM

• Operating Frequency: 2.4 GHz / 5 GHz

• Encryption: 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise, WPA2-Enterprise, WPS support

• Interface: 1x RJ45 for Gigabits BaseT for WAN, 4x RJ45 for Gigabits BaseT for LAN, 2x USB 2.0 Ports, 1x Coaxial Port

• Button: WPS Button, Reset Button, LED on/off Button

• Power Supply:
  • AC Input: 110V~240V (50~60Hz)

  • DC Output : 19 V with max. 3.42 A current

• Dimension (WxDxH): 11.81 x 7.40 x 2.36 inch (w/o Bezel)

• Weight: 2.09 Ibs
