Specifications

• Mfr Part Number: EL-20-3050-32GB
• Processors: Intel Celeron N3050 Processor (1.6GHz Clock Speed, 2.16GHz Max Turbo, 2MB L2Cache, Dual-Core)
• Motherboard: MZBSWIP
• Socket: 1x BGA 1170
• Memory: 2x DDR3L-1600/ 1333 SODIMM Slots, Max Capacity of 8GB
• Slots: 1x Full-size Mini-PCIe Slot (for 3G module or mSATA storage), 1x Half-size Mini-PCIe Slot (for pre-installed WiFi+BT module)
• SATA: 1x SATA3 Port
• Hard Drive: 32GB eMMC
• Audio: Realtek ALC255 7.1 Channel High Definition Audio CODEC
• Video: Integrated Intel HD Graphics; Supports Dual Display
• LAN: 2x Realtek RTL8111HS Gigabit Ethernet Controllers; IEEE 802.11b/g/n/ac Wireless LAN; Bluetooth 4.0
• Ports: 4x USB 3.0 Ports, 1x Micro-B USB 2.0 Port (Side), 1x Micro-B RS232 half-duplex (Side), 1x USB 2.0 Port (via header), 2x Serial Ports (via header), 2x HDMI Ports (rear), 2x RJ45 LAN Ports, 1x Microphone-in/Headphone-out
• Card Reader: SDXC Card Reader
• Power Supply: 65W Power Adapter, 19V DC, 3.42A
• Dimensions: 140.8 x 107.5 x 27.0 mm
• Weight: 560.0 g
• Operating System: Supports Windows 7/ 8.1/ 10 and Android 5.1
