Specifications

• Mfr Part Number: 8260.NGWMG
• Host Interface: PCI Express, USB
• Wireless Transmission Speed: 867 Mbps
• ISM Maximum Frequency: 2.40 GHz
• UNII Maximum Frequency: 5 GHz
• Wi-Fi Alliance: Wi-Fi Certified for 802.11ac, Wi-Fi Certified a/b/g, Wi-Fi Certified n, WMM, WPA, WPA2, and WPS, WPS 2.0, Protected Management Frames, Wi-Fi Direct for peer to peer device connections, Wi-Fi Miracast Source
• IEEE WLAN Standard: IEEE 802.11abgn, 802.11ac, 802.11d, 802.11e, 802.11i, 802.11h, 802.11w
• Architecture: Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes
• Roaming: Supports seamless roaming between respective access points (802.11b, 802.11g, 802.11a/b/g, 802.11a/b/g/n and 802.11ac)
• Bluetooth: Dual Mode Bluetooth 2.1, 2.1+EDR, 3.0, 4.0, 4.1, BLE, 4.2
• Diversity: Suported
• Radio On/Off Control: Supported via software
• Operating Systems: Microsoft Windows 7, Microsoft Windows 8.1, Microsoft Windows Next, Linux (limited feature support)
• Security:
  • Authentication: WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA
  • Authentication Protocols: PAP, CHAP, TLS, GTC, MS-CHAP, MS-CHAPv2
  • Encryption: 64-bit and 128-bit WEP, AES-CCMP
  • Wi-Fi Direct Encryption and Authentication: WPA2, AES-CCMP
  • Product Safety: UL, C-UL, CB (IEC 60950-1)
  • Management Frame Protection: 802.11w (WFA-Protected Management Frames)
• Form Factor: M.2 2230
• Dimensions (WxDxH): 30.0 x 2.4 x 22.0 mm (1.5 mm Max (Top Side) / 0.1 mm Max (Bottom Side))
• Weight: 2.4 g
