Specifications

• Mfr Part Number: CM8068403874212
• Essentials:
  • Product Collection: 9th Generation Intel Core i7 Processors
  • Code Name: Products formerly Coffee Lake
  • Vertical Segment: Desktop
  • Processor Number: i7-9700K
  • Lithography: 14 nm
  • Included Items: Please note: The boxed product does not include a fan or heat sink
  • Use Conditions: PC/Client/Tablet
• Performance:
  • # of Cores: 8
  • # of Threads: 8
  • Processor Base Frequency: 3.60 GHz
  • Max Turbo Frequency: 4.90 GHz
  • Cache: 12 MB SmartCache
  • Bus Speed: 8 GT/s DMI3
  • TDP: 95 W
• Supplemental Information:
  • Embedded Options Available: No
• Memory Specifications:
  • Max Memory Size (dependent on memory type): 128 GB
  • Memory Types: DDR4-2666
  • Max # of Memory Channels: 2
  • Max Memory Bandwidth: 41.6 GB/s
  • ECC Memory Supported: No
• Processor Graphics:
  • Processor Graphics: Intel UHD Graphics 630
  • Graphics Base Frequency: 350 MHz
  • Graphics Max Dynamic Frequency: 1.20 GHz
  • Graphics Video Max Memory: 64 GB
  • 4K Support: Yes, at 60Hz
  • Max Resolution (HDMI 1.4): 4096x2304@24Hz
  • Max Resolution (DP): 4096x2304@60Hz
  • Max Resolution (eDP - Integrated Flat Panel): 4096x2304@60Hz
  • DirectX Support: 12
  • OpenGL Support: 4.5
  • Intel Quick Sync Video: Yes
  • Intel InTru 3D Technology: Yes
  • Intel Clear Video HD Technology: Yes
  • Intel Clear Video Technology: Yes
  • # of Displays Supported: 3
  • Device ID: 0X3E98
• Expansion Options:
  • Scalability: 1S Only
  • PCI Express Revision: 3.0
  • PCI Express Configurations: Up to 1x16, 2x8, 1x8+2x4
  • Max # of PCI Express Lanes: 16
• Package Specifications:
  • Sockets Supported: FCLGA1151
  • Max CPU Configuration: 1
  • Thermal Solution Specification: PCG 2015D
  • TJUNCTION: 100°C
  • Package Size: 37.5mm x 37.5mm
• Advanced Technologies:
  • Intel Optane Memory Supported: Yes
  • Intel Turbo Boost Technology: 2.0
  • Intel vPro Platform Eligibility: Yes
  • Intel Hyper-Threading Technology: No
  • Intel Virtualization Technology (VT-x): Yes
  • Intel Virtualization Technology for Directed I/O (VT-d): Yes
  • Intel VT-x with Extended Page Tables (EPT): Yes
  • Intel TSX-NI: Yes
  • Intel 64: Yes
  • Instruction Set: 64-bit
  • Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
  • Idle States: Yes
  • Enhanced Intel SpeedStep Technology: Yes
  • Thermal Monitoring Technologies: Yes
  • Intel Identity Protection Technology: Yes
  • Intel Stable Image Platform Program (SIPP): Yes
• Security & Reliability:
  • Intel AES New Instructions: Yes
  • Secure Key: Yes
  • Intel Software Guard Extensions (Intel SGX): Yes with Intel ME
  • Intel Memory Protection Extensions (Intel MPX): Yes
  • Intel OS Guard: Yes
  • Intel Trusted Execution Technology: Yes
  • Execute Disable Bit: Yes
  • Intel Boot Guard: Yes
