Specifications

• Mfr Part Number: MPX-5001-ACAAW-US
• Features:
  • Advanced Circuit Design - Active PFC + PWM combined with dual forward topology and double EMI filter enhances power output efficiency and increases the performance and stability of your system
  • Silent and Durable Fan -  Cooler Master's 120mm HDB temperature control fan can operate more smoothly without friction, which makes it quiet and more durable
  • Green Power - Compliant with ErP 2013 Lot6, which guarantees that your PSU will use less than 0.5W on system standby and lower than 45% transferring efficiency on 5V standby

  • Safety Guardian - Full protection (OCP/OVP/SCP/OPP) with built-in Over Temperature Protection (OTP). Minimizes the risk of damage from power outages

• Type: ATX 12V V2.31
• Output Capacity: 500V
• Input
  • Voltage: 100 - 240V AC
  • Current: 4 - 8A
  • Frequency: 50 - 60Hz
• PFC: Active PFC (>0.9 typical)
• Power Good Signal: 100 - 500ms
• Hold Up Time: >10ms at 100% full load
• MTBF: >100,000 Hours
• Fan: 120mm HDB fan
• Efficiency: 80% Typically Load
• Protection: OVP/UVP/OPP/OTP/OCP/SCP
• Output: +3.3V @ 20A, +5V @ 20A, +12V @ 38A, -12V @ 0.3A, +5Vsb @ 2.5A
• Connectors: 1x 20+4pin Motherboard Connector, 1x 4+4pin CPU 12V Connectors, 2x 6+2pin PCI-Express Connectors, 6x SATA Connectors, 3x 4pin Peripheral Connectors, 1x 4pin Floppy Connector
• Regulatory: TUV, CE, BSMI, FCC, cTUV-Rhus, KC, CCC, EAC, RCMC
• Dimensions: 150.0 x 140.0 x 86.0 mm
