Specifications

• Mfr Part Number: X299CREATION
• CPU: LGA2066
  • Supports Intel Core X-Series Processor
• Chipset: Intel X299
• Memory: 8x DDR4-4200(OC)/ 4100(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3000(OC)/ 2933(OC)/ 2800(OC)/ 2666/ 2400/ 2133 MHz DIMM Slots (4-channels), Max Capacity of 128GB; 8x DDR4-4133(OC)/ 4000(OC)/ 3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3000(OC)/ 2933(OC)/ 2800(OC)/ 2666/ 2400/ 2133 DIMM Slots (2-channels), Max Capacity of 64GB
• Slots: 4x PCI-Express 3.0 x16 Slots, 1x PCI-Express 3.0 x1 Slot
• Multi-Graphics: Supports AMD CrossFireX and NVIDIA SLI Technology
• Storage:
  • SATA: 8x SATA3 Ports
  • M.2: 3x M.2 Ports (w/ Key M); Two support SATA3 & PCI-Express 3.0 x4 & type 2242/ 2260/ 2280/22110 storage devices, one supports PCI-Express 3.0 x4 & type 2242/ 2260/ 2280 storage devices
  • U.2: 1x U.2 Port, Supports PCIe 3.0 x4 NVMe storage
• Audio: Realtek ALC1220 7.1-Channel High Definition Audio CODEC
• LAN: Intel I219-V Gigabit Ethernet Controller; Realtek RTL8125-CG 2.5G LAN controller; Intel Wireless-AC 9260 802.11 a/b/g/n/ac Wireless LAN (2.4/5 GHz); Bluetooth 2.1, 2.1+EDR, 3.0,4.0, 5
• Ports: 3x USB 3.1 Gen2 Ports (1 Type-A rear, 1 Type-C rear, 1 Type-C via header), 10x USB 3.1 Gen1 Ports (6 rear, 4 via header), 6x USB 2.0 Ports (2 rear, 4 via headers), 1x PS/2 Port, 1x Optical S/PDIF OUT, 2x RJ45 LAN Ports, Audio I/O Jacks
• Power Connector: 1x 24-pin ATX Main Power Connector, 3x 8-pin ATX 12V Power Connectors, 1x flat 4-pin ATX 12V Power Connector

• Form Factor: EATX, 12.0 x 10.7 inch / 30.5 x 27.2 cm
