Specifications

• Mfr Part Number: MPX-6001-ACAAB-US
• Features:
  • DC-DC Circuit Design - The DC-DC circuit design offers your system more reliable and stable output voltages, providing more consistent power delivery at up to 40°C
  • Durable LDB Bearing - Cooler Master 120mm Silencio FP fan combines sealed LDB bearings with quiet fan blades offering a long lifetime of quiet cooling.
  • Quality Capacitors - Solid, high quality capacitors are used in the MWE Bronze power supply for increased product lifespan and higher temperature resistance
  • Sleeved Cables - provide easier cable management, offering a clean and professional look. They also save space for better airflow within the PC system, improving thermal performance and heat dissipation
  • Low Standby Power - The MWE Bronze will consume no more than 0.5W when your PC is in standby mode, complying with ErP 2013 lot 6
• Type: Intel ATX 12V V2.31
• Output Capacity: 600W
• Input
  • Voltage: 100 - 240V AC
  • Current: 10 - 5A
  • Frequency: 50 - 60Hz
• PFC: Active PFC
• Power Good Signal: 100 - 500 ms
• Hold Up Time: 16ms at 80% load
• MTBF: >100,000 Hours
• Fan: 120mm Silencio FP Fan
• Efficiency: 85% Typically Load
• Protection: OVP / OPP / OTP / SCP / OCP
• Output: +3.3V @ 20A, +5V @ 20A, +12V @ 50A, -12V @ 0.3A, +5Vsb @ 3A
• Connectors: 1x 20+4pin Motherboard Connector, 1x 4+4pin CPU 12V Connector, 4x 6+2pin PCI-Express Connectors, 8x SATA Connectors, 4x 4pin Peripheral Connectors, 1x 4pin FDD Cable Connector
• Regulatory: TUV-RH, CE, CCC, KC, EAC, RCM, cTUVus, FCC, BSMI
• Dimensions: 150.0 x 140.0 x 86.0 mm
