Specifications

• Mfr Part Number: VNP-PA500X-13ZL
• Display Technology: 0.79" LCD w/ MLA
• Resolution:
  • Native: XGA 1024 x 768
  • Maximum: UXGA 1600 x 1200
• Light Output (lumens): 5000 Normal / Eco = Approx. 80% of Normal Mode
• Contrast Ratio (up to): 2000:1
• Lamp Type: 330W AC; 264W Eco
• Lamp Life (up to): 3000 Hours (normal); 4000 Hours (eco)
• Screen Size (diagonal): 25 to 500 inch / 0.64 to 12.7 m
• Throw Ratio: Variable
• Projection Distance: 2.5 to 68.5 ft / 0.74 to 20.9 m
• Projector Angle: 13.7 to 14.5° (wide); 10.3 to 10.8° (tele)
• Lens:
  • Zoom: 1.00 ~ 1.33
  • Focus: Manual
  • F-number, fnumber: F= 1.7 ~ 2.2mm, f= 24.4 ~ 32.5mm
  • Shift: Mechanical -0.1 to +0.5 Vertical, +/-0.3 Horizontal
• Keystone Correction: ±40° (horizontal), ±30° (vertical)
• Scan Rate: Horizontal- 15 ~ 108 kHz; Vertical- 48 ~ 120 Hz
• Supported Video Standards: NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM
• SD/HD Video Signal Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
• PC Signal Compatibility: VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA
• Macintosh Compatibility: Yes
• Input/Output Terminals:
  • RGB1 (analog): VGA 15-pin D-sub
  • RGB2 (analog): VGA 15-pin D-sub
  • RGB3 (analog): 5-BNC
  • RGB4 (digital): HDMI w/ HDCP
  • RGB5 (digital): DisplayPort
  • Video 1: RCA
  • Video 2: S-Video
  • Audio 1: Mini Stereo
  • Monitor out: VGA 15-pin D-sub
  • Audio out: Yes
• Audio: 10W Mono
• External Control: RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN (optional)
• Sync Compatiblity: Separate Sync/ Composite Sync/ Sync on G
• Networking: RJ-45 Monitoring
• Power: 100 ~ 240V AC, 50/60 Hz
• Input Current: 5.1 A
• Power Consumption (Normal/ECO Mode/Standby/Standby Power Saving): 464W/ 372W/ 16W/ 0.2W
• Installation Orientation: Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
• Fan Noise: 38dB (normal) / 31dB (eco)
• Regulations: USA UL 1950 FCC Class B, Canada CSA 950 (C-UL), NOM
• Dimensions (WxDxH): 19.7 x 14.4 x 6.5 inch / 499.0 x 366.0 x 164.0 mm
• Weight: 17.0 lbs / 7.7 kg
