Specifications

• Mfr Part Number: CA-H510I-W1
• Case Type: Mid-Tower ATX
• Color: Matte Black
• Material: SECC Steel and Tempered Glass
• M/B Type: Mini-ITX, MicroATX, and ATX
• Drive Bays:   3x 3.5", 3x 2.5"
• Filters: All Air Intakes
• Included Accessories:
  • Installation screws
  • 10 x Cable ties
  • 1x Headset Audio Jack splitter (4 pole to 3 pole)

• Expansion Slots: 7
• Radiator Support:Front: 2x 140 or 2x 120mm with Pull  ,Rear: 1x 120mm
• Fan Support:
  • Front: 2x 120mm or 2x 140mm Fan Vents
  • Top: 1x 120mm/ 1x 140mm (1 Aer F120 Case Version included)
  • Rear: 1x 120mm (1 Aer F120 Case Version included)
• I/O Panel: 1x USB 3.1 Gen 2 Type-C , 1x USB 3.1 Gen 1 Type-A , 1x Headset audio Jack
• Maximum Compatibility:
  • Cable Management: 1 19-23mm
  • GPU Clearance: Up to 381mm
  • CPU Cooler Height: Up to 165mm
  • Front Radiator: 60mm
  • Rear Radiator: 60mm
  • Reservoir & Pump: Up to 180mm (Along cable bar), Up to 86mm (Along bottom panel)
• Dimensions (WxHxD): 210.0 mm x 460.0 mm x 428.0 mm (with feet)
• Weight: 6.8kg
• Warranty: 2 years
