Specifications

• Mfr Part Number: EH503E

• Display Technology: DLP
• Native Resolution: 1080p 1920 x 1080

• Brightness: 5200 ANSI Lumens
• Contrast: 2000:1
• Light Source: Lamp
• Lamp Life: 4000/3000 hours (Eco/Bright mode)
• Lens Options: Extra Long - 3.0 ~ 5.0 (1.67x zoom), Long - 1.93~2.89:1 (1.5x zoom), Semi Short - 1.1 ~ 1.3:1 (1.18x zoom), Short - 0.77:1 (Fixed), Standard - 1.54~1.93:1 (1.25x zoom)

• Throw Ratio: 0.77 ~ 5.0:1 (lens dependent), 0.77 ~ 5.0:1 (Lens dependent)

• Zoom Type: Dependent upon lens
• Lens Shift: Max. Lens Shift -15 to +55% V, ±5% H (Manual)

• I/O Connectors: HDMI (1.4a 3D support), DVI-D, DisplayPort, 5BNC, Component Video, 2x VGA (RGB/YPbPr), S-Video, Composite, 5x Audio In (RCA/3.5mm), Audio Out 3.5mm, VGA Out, RJ45, RS232, USB (Remote Mouse), +12v Trigger, Wired Remote, 3D-Sync In, 3D-Sync Out

• Keystone Correction: ±40° Vertical, (±20° Vertical in System)
• Aspect Ratio: 16:9 Native, 16:10 and 4:3 Compatible
• Projection Screen Size: Dependent upon lens
• Projection Distance: Dependent upon lens

• Uniformity: 85% (center)

• Computer Compatibility: HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible
• Video Compatibility: PAL (625/576i/p), SECAM, NTSC (525/480i/p), HDTV (720p, 1080i/1080p)

• 3D Support: Mandatory HDMI 1.4 3D formats, 120Hz frame sequential (up to 720p)
• Horizontal Scan Rate: 15 ~ 91kHz

• Vertical Scan Rate: 24– ~ 85Hz (120Hz for 3D)

• Displayable Colors: 1073.4 million colors (10 bit)
• Noise Level (Eco mode): 37dB (Eco mode)
• Power Supply: 100 ~ –240V, 50– ~ 60Hz, auto-switching

• Power Consumption: 460W (max) bright mode, <0.5w standby mode

• Lamp Type: 370W
• Operating Conditions: 5 ~ 40 C, max. humidity 85%, max. altitude 3000m
• Security: 4-digit PIN code, Kensington lock port, security bar

• On Screen Display: 19 Languages - English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish, Greek, Norwegian/Danish, Hungarian, Czech, Turkish, Romanian, Farsi, Arabic

• Remote Control: Infra-red remote control, Multiple IR code sets for controlling multiple units, Wired connection sup
• 360-operation: Not supported
• Projection method: Not supported

• Conformance: CE, TUV-GS, CB

• Dimensions (WxDxH): 430.0 x 340.0 x 183.0 mm
• Weight: 8.6 kg (without lens)

• RoHS Compliant
