Specifications

• Mfr Part Number: ZW300UST
• Resolution: WXGA 1280 x 800
• Brightness: 3200 Lumens
• Contrast Ratio: 100,000:1 (dynamic black enabled) / 22,000:1
• Throw Ratio: 0.27:1
• Zoom Type: Digital 0.8 ~ 2.0
• I/O Connectors: 2xHDMI with MHL, VGA-In, VGA-Out, Composite Video In, 2xAudio in (3.5mm/RCA audio), Mic-In (3.5mm), Audio out (3.5mm), RS232, USB-A (Power), USB-B (Service), RJ45 (LAN)
• Speaker: 10 Watt speaker
• Audio: 10 Watt speaker
• Keystone Correction: ± 40° Vertical
• Aspect Ratio: 16:10 (native), 16:9, 4:3, Auto
• Offset: 120% ±3%
• Projection Screen Size: 85" - 115"
• Projection Distance: 19.4" - 27"
• Projection Lens: F=2.5~ 3.26, f=20.91 ~ 32.62 mm manual focus
• Uniformity: 80%
• Maximum Resolution: WUXGA (1920 x 1200)
• Computer Compatibility: SVGA, VGA, SXGA, UXGA, XGA,WXGA, HD, Mac
• 3D Compatibility: Supports all HDMI 1.4a mandatory 3D formats (Frame pack, side-by-side, top-bottom) and up converts frame rate from 60Hz to 120Hz or 24Hz to 144Hz (i.e. 60 or 72 frames per eye). 3D glasses are needed and are sold separately. Refer to user manual for details.
• Horizontal Scan Rate: 15.375 - 91.4KHz
• Vertical Scan Rate: 24 - 85 Hz (120Hz for 3D feature)
• Displayable Colors: 1.07 Billion
• Noise Level (Eco mode): 32 dB
• Power Supply: AC input 90 - 264V, 50 - 60 Hz
• Power Consumption: 335W (Bright), 225W (ECO)
• Lamp Type: Laser Phosphor
• Operating Conditions: Operating Temp @ Sea Level to 10000 feet = 73F (max); must manually switch to high altitude mode @ 5000 feet & above (using OSD)
• Operating Temperature: 41 - 104°F (5 - 40°C), 85% max humidity
• Security: Kensington Lock lock, security bar and keypad lock
• Remote Control: Full Function Remote
• Standard Accessories: AC power cord, VGA to VGA cable, remote control, batteries for remote, multilingual CD-ROM user ™s manual, quick start card, and warranty card
• Optional Accessories: Universal ceiling mount, DLP Link 3D glasses, Wireless HDMI system, Remote, HDCast Pro
• Optional Wireless: Yes
• Projection method: Front, rear, ceiling mount, table top
• Dimensions (WxDxH): 15.0 x 5.0 x 12.5 inch
• Weight: 12.3 lbs
• RoHS Compliant
