Specifications

• Mfr Part Number: PA762
• Features:
  • Includes all necessary wall and display attachment hardware
  • The I-Shaped Adaptor plate's innovative design helps avoid blocking connections on back of display
  • Universal mount fits displays with mounting patterns 200 x 100 to 600 x 400mm
  • ±5° of roll for post installation display leveling
  • Up to ±90° of pivot allows for perfect display positioning
  • +15/-5° of tilt for optimal viewing angles
  • Retracts to 3.00" (76mm) to save space
  • Extends 21.32" (542mm) from the wall
  • Design is UL listed and tested to four times stated load capacity
• Screen Size:
  • Minimum: 39"
  • Maximum: 90"
• VESA Pattern: 600 x 400 mm
• Mounting Pattern: 600 x 400 mm
• Tilt: +15 / -5
• Swivel Yaw: +45 / -45
• Security Features: Non-Security Hardware
• Finish: High Gloss
• Distance From Wall: 0 inch/ 76 - 542mm

• Color: Black
• Dimensions: 24.38 x 16.75 x 3.00 - 21.32 inch / 619.0 x 425.0 x 76.0 - 542.0 mm
• Weight: 150.0 lbs / 68.0 kg
