Specifications

• Mfr Part Number: QSW-1208-8C-US

• 10G SFP+ (fiber) ports: 4
• 10G SFP+ (fiber) and RJ-45 (copper) ports (combo): 8
• Form Factor: Desktop/rackmount

• Switching capacity: 240 Gbps

• MAC address caching capacity: 27K
• Number of priority queues: 8
• Jumbo frame support: Up to 9K packet size

• Power Supply Unit: 100 - 240 V AC, 50 -60 Hz, max. 2.5 A
• Power Consumption:
  • All ports used, line-rate traffic: 49 W
  • Link-down standby: 21W
• Fan: 2x low-noise smart fans

• Sound Level: @ 25°C - 18.7 dB(A)

• Electromagnetic compliance: Class A
• LED Indicators:
  • Per switch: Power
  • Per port: Speed, link, activity
• Supported standards:
  • IEEE 802.3 Ethernet
  • IEEE 802.3u 100BASE-TX
  • IEEE 802.3ab 1000BASE-T
  • IEEE 802.3x Full-Duplex Flow Control
  • IEEE 802.1p Class of Service
  • IEEE 802.3az Energy Efficient Ethernet (EEE)

  • IEEE 802.3an 10GBASE-T
  • IEEE 802.3bz 5Gbps and 2.5Gbps Ethernet Over Copper Twisted Pair Cable
  • IEEE 802.3ae 10-Gigabit Ethernet Over Fiber
  • IEEE 802.3aq 10-Gigabit over Fiber (10GBASE-LRM)
  • IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
• Dimensions (WxDxH): 285.0 x 233.0 x 43.0 mm
• Weight: 2.15 kg
• Package content: QSW-1208-8C, Power Cord, Rackmount kit, Rubber feet, Quick Installation Guide (QIG)
