Zoom QNAP TS-1232XU-RP-4G-US Alpine AL-324 ARMv8 Cortex-A57 1.7GHz/ 4GB DDR4/ 4GbE/ 12SATA3/ USB3.1/ 12-Bay 2U Rackmount NAS for SMB

QNAP TS-1232XU-RP-4G-US Alpine AL-324 ARMv8 Cortex-A57 1.7GHz/ 4GB DDR4/ 4GbE/ 12SATA3/ USB3.1/ 12-Bay 2U Rackmount NAS for SMB

$2,188.75 $2,346.34

Specifications

  • Mfr Part Number: TS-1232XU-RP-4G-US
  • Hardware:
    • CPU: Alpine AL-324 ARMv8 Cortex-A57 Processor (1.7GHz Clock Speed, Quad Core)
    • Encryption Engine
    • System Memory: 4GB DDR4 (1x 4GB)
    • Maximum Memory: 16GB (1x 16GB)
    • Memory Slot: 1x DDR4 Long-DIMM slot
    • Drive Bay: 12x 3.5-inch SATA 6 Gbps bays
    • Drive Compatibility: 3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
    • LAN Port: 2x RJ45, 2x 10GbE SFP+
    • USB Port: 4x USB 3.1 Gen 1 Type-A
    • PCIe Slot: Slot 1 - 2.0 x2
    • Sound Level: 31.7 dB(A)
    • Operating System: QTS 4.3.4 (embedded Linux)
  • Network & Virtual Switch:
    • TCP/IP - Dual stack (IPv4 and IPv6)
    • Jumbo frame (failover, multi-IP settings, port trunking/NIC teaming)
    • DHCP server and client
    • USB Wi-Fi adapter
    • Virtual switch
      • Virtual switch editing in Virtualization Station
      • Combining virtual machines and containers in the same virtual switch
      • Network Address Translation (NAT)
      • Spanning Tree Protocol (STP)
    • WirelessAP Station
  • Security:
    • Network access protection with auto-blocking (SSH, Telnet, HTTP(S), FTP, CIFS/SMB, and AFP)
    • Host access control for shared folders (CIFS/SMB)
    • AES 256-bit folder-based and volume-based encryptions which are validated by FIPS 140-2 CAVP (Cryptographic Algorithm Validation Program)
    • 256-bit external drive encryption (AES)
    • Importing of SSL certificates from Let's Encrypt
    • Instant alerts through email, SMS, push service, audio, and LCD panel
    • 2-step verification
  • Storage Management:
    • Storage space utilization monitoring
    • Flexible volumes and LUNs with thin provisioning and space reclaiming
    • Supported RAID types
      • 4-bay - RAID 0, 1, 5, 6, 10, JBOD, Single
      • 8-bay (and above) - RAID 0, 1, 5, 6, 10, 50, 60, JBOD, Single
    • RAID hot spare and global hot spare
    • RAID rebuild speed customization
    • Advanced secure data erase
    • Storage pools
    • Qtier Technology (automated storage tiering)
      • Automatic or scheduled data tiering
      • IO-aware auto tiering
      • Shared folder tiering on demand
    • Snapshots - The maximum number of snapshots varies depending on installed memory
      • Volume and LUN snapshots
      • Snapshot Dashboard
      • Snapshot Manager
      • Snapshot Cloning
      • Snapshot Vault
      • Snapshot Replica
      • Unify Snapshot Directory
      • Support for Windows previous versions (CIFS/SMB)
      • Snapshot Agent for Microsoft Windows and VMware vSphere
      • Max. snapshots (per volume or block-based LUN/per NAS) - 32/64 for 4 GB models, 64/256 for 4 GB models
    • Online volume expansion
    • Online storage pool expansion
    • Online RAID capacity expansion
    • Online RAID level migration
    • SMART data migration
    • Storage expansion using QNAP expansion units
    • JBOD enclosure roaming
    • SSD read-only or read-write cache
    • Bad block scan and hard drive S.M.A.R.T test
    • Bad block recovery and RAID recovery
    • Bitmap support
  • File System:
    • Internal HDD: EXT4
    • External HDD: EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT
  • Form Factor: 2U Rackmount
  • Fan: 2x 7 cm fans (12 V DC)
  • Power Consumption: HDD sleep - 42.61 W; In Operation - 77.09 W
  • Power Supply: 2x ATX 250 W, 100 - 240 V AC, 50/60 Hz, 5A - 2.5A
  • Dimensions (WxDxH): 18.98 x 21.02 x 3.50 inch / 482.0 x 534.0 x 89.0 mm
  • Weight: 28.66 lbs / 13.0 kg

Vendor: QNAP
