Specifications

• Mfr Part Number: TS-1253BU-RP-4G-US
• Hardware:
  • CPU: Intel Apollo Lake J3455 Processor (1.5GHz, quad-core)

  • System Memory: 4GB DDR3L (2x 2GB)
  • Ram slot: 2x SODIMM (MAX. 8GB)

  • Flash Memory: 4GB eMMC

  • PCIe Slot: 1x PCI-Express 2.0 x2 Slot

  • Hard Drive Tray: 12x SATA 6Gb/s, 3Gb/s HDD or SSD; Hot-swappable

  • USB: 4x USB 3.0 Ports (Rear)

  • LAN Port: 4x Gigabit LAN Ports

  • HDMI Output: 1x HDMI Port

  • LED Indicator: System Status, HDD,USB, LAN

  • Button: Power, Reset

  • System Warning: Buzzer
  • Sound Level: Operating low speed - 33.2 dB(A)

  • Operating System: QTS 4.3 (embedded Linux)

• Networking:
  • TCP/IP (IPv4 & IPv6: Dual Stack)

  • Jumbo frame (failover, multi-IP settings, port trunking/NIC teaming)

  • DHCP client, DHCP server

  • USB Wi-Fi Adapter Support

  • Virtual Switch
    • Supports editing the Virtual Switches in Virtualization station

    • Supports combining virtual machines and containers to the same Virtual Switch

    • Supports NAT (Network Address Translation)

    • Supports STP (Spanning Tree Protocol)

  • USB QuickAccess
  • WirelessAP Station

• Security:
  • Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP

  • CIFS host access control for shared folders

  • FIPS 140-2 validated AES 256-bit volume-based and shared folder data encryption2

  • AES 256-bit external drive encryption

  • Importable SSL certificates. Supports certificates from Let's Encrypt

  • Instant alerts via email, SMS, beep, push service, and OLED panel

  • 2-step verification
• Storage Management:
  • Storage Space Utilization monitoring
  • QNAP flexible Volume/LUN with thin provisioning and space reclaim

  • Disk volume types: RAID 0,1, 5, 6, 10, + hot spare, JBOD, single

  • Supports storage pools

  • Supports Qtier auto-tiering technology
  • Supports snapshots
    • Supports Volume/LUN snapshot
    • Snapshot manager

    • Snapshot clone

    • Snapshot vault
    • Snapshot replica

    • Snapshot agent for Microsoft Windows and VMware vSphere
  • Online volume expansion

  • Online storage pool expansion

  • Online RAID capacity expansion and online RAID level migration

  • SMART data migration

  • Storage expansion via QNAP UX-500P/UX-800P expansion units

  • JBOD enclosure roaming
  • SSD read-only/read-write cache

  • Bad block scan and hard drive S.M.A.R.T.
  • Bad block recovery & RAID recovery

  • Bitmap support
• File System:
  • Internal HDD: EXT4
  • External HDD: EXT3, EXT4, NTFS, FAT32, HFS+, exFAT

• Form Factor: 2U, rack mountable

• Fan: 2x 70mm Fans (12V DC)

• Power Supply: ATX 250W (Redundant)

• Power Consumption:
  • HDD Sleep: 42.7W
  • Typical Operation: 75.9W

• Dimensions: 3.50 x 18.98 x 21.02 inch / 89.0 x 482.0 x 534.0 mm

• Weight: 35.58 lbs / 16.14 kg
