Specifications

• Mfr Part Number: TS-1677XU-RP-2600-8G
• Hardware:
  • CPU: AMD Ryzen 5 2600 6-core 3.4 GHz processor, Turbo Core 3.9 GHz
  • CPU Architecture: 64-bit x86
  • System Memory: 8 GB UDIMM DDR4 (2 x 4GB)
  • Maximum Memory: 64 GB (4 x 16 GB)
  • Memory Slot: 4 x Long-DIMM DDR4
  • Flash Memory: 5GB (Dual boot OS protection)
  • Drive Bay: 16 x 3.5-inch SATA 6Gb/s, 3Gb/s
  • Drive Compatibility:
    • 3.5-inch SATA hard disk drives

    • 2.5-inch SATA hard disk drives

    • 2.5-inch SATA solid state drives
  • Gigabit Ethernet Port (RJ45) 2
  • 10 Gigabit Ethernet Port: 2 x 10GbE SFP+ SmartNIC port
  • PCIe Slot: 4
    • Slot 1: PCIe Gen 3 x4

    • Slot 2: PCIe Gen 3 x8 or PCIe Gen 3 x4

    • Slot 3: PCIe Gen 3 x4

    • Slot 4: PCIe Gen 3 x8 or PCIe Gen 3 x4
  • USB 3.0 port 4
  • USB 3.1 Gen 2 (10Gbps) Port
    • 1 x Type-C USB 3.1 Gen2 5V/3A 10Gbps

    • 1 x Type-A USB 3.1 Gen2 5V/1A 10Gbps
  • Form Factor 3U Rackmount
  • LED Indicators HDD 1-16, Status, LAN, storage expansion port status
  • Buttons Power, Reset
• Networking:
  • TCP/IP (IPv4 & IPv6: Dual Stack)
  • NICs with jumbo frame (failover, multi-IP settings, port trunking/NIC teaming)
  • Service binding based on network interfaces
  • Squid Proxy server
  • Proxy client
  • DHCP client, DHCP server
  • Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
  • UPnP & Bonjour Discovery
  • USB Wi-Fi Adapter Support
• Security:
  • Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
  • CIFS host access control for shared folders
  • FIPS 140-2 validated AES 256-bit volume-based and shared folder data encryption
  • AES 256-bit external drive encryption
  • Importable SSL certi cates
  • Instant alert via E-mail, SMS, beep,and push service
  • 2-step veri cation
• Storage Management:
  • Storage space utilization monitoring

  • Flexible volumes and LUNs with thin provisioning and space reclaiming

  • Supported RAID types

    • RAID 0, 1, 5, 6, 10, 50, JBOD, Single

  • RAID hot spare and global hot spare

  • RAID rebuild speed customization

  • Advanced secure data erase

  • Storage pools
  • Qtier Technology

    • (automated storage tiering) Automatic or scheduled data tiering

    • IO-aware auto tiering

    • Shared folder tiering on demand
  • Snapshots

    • Volume and LUN snapshots

    • Snapshot Dashboard

    • Snapshot Manager

    • Snapshot cloning

    • Snapshot Vault

    • Snapshot Replica

    • Unified Snapshot Directory

    • Support for Windows Previous Versions (CIFS/SMB)

    • Snapshot Agent for Microsoft Windows and VMware vSphere
  • Online volume expansion

  • Online storage pool expansion

  • Online RAID capacity expansion

  • Online RAID level migration

  • SMART data migration

  • Storage expansion using QNAP expansion units

  • JBOD enclosure roaming

  • SSD read-only or read-write cache

  • Bad block scan and hard drive S.M.A.R.T test.

  • Bad block recovery and RAID recovery

  • Bitmap support
• File System:
  • Internal hard drive (EXT4)

  • External hard drive (EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT)
• Form Factor: 3U Rackmount
• Fan: System fan: 4 x 92mm, 12VDC
• Power Supply Unit: 500W(x2), 100-240V
• Power Consumption:136.45 W(Operating Mode, Typical)
• Dimensions: 5.12 x 18.94 x 22.58 inch
• Weight: 47.13 lbs
