Specifications

• Mfr Part Number: TS-932X-2G-US
• Hardware:
  • CPU: Alpine AL-324 ARM Cortex-A57 Processor (1.7GHz Clock Speed, Quad Core)
  • Encryption Acceleration
  • System Memory: 2GB DDR4 2400 (1x 2GB)
  • Maximum Memory: 16GB (1x 16GB)
  • Memory Slots: 1x SO-DIMM slot
  • Flash Memory: 512 MB NAND Flash
  • Drive Type: 5x 3.5-inch SATA 6 Gbps bays, 4x 2.5-inch SATA 6 Gbps bays; Hot-swappable
  • Drive Compatibility:
    • 3.5-inch bays: 3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
    • 2.5-inch bays: 2.5-inch solid state drives
  • LAN Port: 2x 10GbE SFP+ LAN Ports, 2x Gigabit RJ45 LAN Ports
  • USB: 3x USB 3.0 Ports (1 front, 2 rear)
  • Audio: 1x Built-in speaker, 1x 3.5mm line out jack
  • LED Indicator: Status/Power, LAN, USB, HDD 1-5, SSD 1-4

  • Button: Power, Reset, USB One- touch-copy
  • System Warning: Voice prompts
  • Sound Level: Sound pressure (LpAm) - 18.7 dB(A)
  • Operating System: QTS 4.3.4 (embedded Linux)
• Networking:
  • TCP/IP - Dual Stack (IPv4 & IPv6)
  • Service binding based on network interfaces
  • Squid Proxy server
  • Proxy client
  • DHCP client, DHCP server
  • Protocols - CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
  • UPnP & Bonjour Discovery
  • USB Wi-Fi Adapter Support
• Security:
  • Network access protection with auto-blocking - SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
  • CIFS host access control for shared folders
  • FIPS 140-2 validated AES 256-bit volume-based and shared folder data encryption
  • AES 256-bit external drive encryption
  • Importable SSL certi cates
  • Instant alert via E-mail, SMS, beep,and push service
  • 2-step verification
    • Data encryption functions may be unavailable in accordance with the legislative restrictions of some countries
• Storage Management:
  • Storage space utilization monitoring
  • Flexible volumes and LUNs with thin provisioning and space reclaiming
  • Disk volume types
    • RAID RAID 0/1/5/6/10/50/60, + hot spare, single, JBOD
    • RAID hot spare and global hot spare
    • RAID rebuild speed customization
    •  Advanced secure data erase
  • Storage pools
  • Qtier Technology (automated storage tiering)
  • Snapshots
    • Volume and LUN snapshots
    • Snapshot Dashboard
    • Snapshot Manager
    • Snapshot cloning
    • Snapshot Vault
    • Snapshot Replica
    • Unified Snapshot Directory
    • Support for Windows Previous Versions (CIFS/SMB)
    • Snapshot Agent for Microsoft Windows and VMware vSphere
    • 2GB SKU - Max. 32 snapshots per volume/block-based LUN; max. 64 per NAS
    • 8GB SKU - Max. 64 snapshots per volume/block-based LUN; max. 256 per NAS
  • Online volume expansion
  • Online storage pool expansion
  • Online RAID capacity expansion and online RAID level migration
  • SMART data migration
  • Bad block scan and hard drive S.M.A.R.T.
  • Bad block recovery and RAID recovery
  • Bitmap support
• File System:
  • Internal HDD: EXT4
  • External HDD: EXT3, EXT4, NTFS, FAT32, HFS+
• Form Factor: Tower
• Fan: 1x 14cm smart fan (12V DC)

• Power Consumption (with 5 x HDDs and 4 x SSDs installed):
  • HDD standby: 21.66W
  • In operation: 42.15W
• Power Supply Unit: 120W AC external adapter, 100-240V

• Dimensions (WxDxH): 8.86 x 8.82 x 7.17 inch / 225.0 x 224.0 x 182.0 mm
• Weight: 7.78 lbs / 3.53 kg
