Specifications

• Mfr Part Number: C7H61-B
• CPU: LGA1155
  • Supports 3rd and 2nd Generation Intel Core i7/ i5/ i3, Pentium and Celeron Processors
• Chipset: Intel H61 Express
• Memory: 2x 240pin DDR3-1600/1333 MHz DIMM Slots, Non-ECC, Unbuffered, Max Capacity of 16GB
• Slots: 1x PCI-Express 3.0 x16 Slot, 1x PCI-Express 2.0 x1 Slot, 5x 32-bit PCI Slots (5V Key)
• SATA: 2x SATA3 Ports, 4x SATA2 Ports
• Audio: Realtek ALC888S-VD2 High Definition Audio CODEC
• LAN: Intel 82579V and 82574L Gigabit Ethernet Controller
• Ports: 2x USB 3.0 Ports (header), 10x USB 2.0 Ports (6 rear, 4 via headers), 1x VGA Port, 1x DisplayPort, 1x HDMI Port, 2x RJ45 LAN Ports, 8x Serial Ports (6 RS-232, 2 RS232/485/422), Audio I/O Jacks
• Form Factor: ATX, 12.0 x 9.6 inch / 30.5 x 24.4 cm
