Specifications

• Mfr Part Number: MBE-628E-420
• Processor Blade: Up to 28 hot-plug DP Xeon E5-2600 v3 MicroBlade
• Module Support: Supports Intel based blades
• LED: Power LED, Fault LED
• Gigabit Ethernet Switch/Pass-Through Module: Supports two hot-plug MBM-GEM-001 (IntelFM5224) with 56x 1Gbps downlinks; 2x 40Gbps QSFP or 8x 10Gbps SFP+ uplinks and 1Gbps RJ45
• Management Module: Supports up to two hot-plug Chassis Management Modules (CMM) providing remote KVM and IPMI 2.0 functionalities
• Cooling Design: Up to 8 Cooling Fans
• Power Supply: Up to 4x hot-swap High-efficiency 2000W, N+1 or N+N redundant power supplies
• Dimensions (WxDxH): 17.67 x 32.00 x 10.43 inch
• Management module not included in the enclosure
