Specifications

• Mfr Part Number: PWS-502-PQ
• Type: Single, ATX12V
• Total Power: 500 W
• Input Voltage: 100~240V
• Input Current: 3.5~7A
• Input Frequency Range: 50~60Hz
• Average Efficiency: 84.11%
• Typical Efficiency (50% Load): 85.83%
• Output: +5V @ 20A, +3.3V @ 15A, +12V1 @ 16A, +12V2 @ 18A, +12V3 @ 18A,+12V4 @ 18A, 5VSB @ 3A
• Active PFC: Yes
• Connector: 1x 24pin Main Power
• Form Factor: 2U
• Dimensions (WxLxH): 150.0 x 140.0 x 86.0 mm
• Weight: 2.2 kg
