Specifications

• Mfr Part Number: SYS-5039MS-H12TRF
• Motherboard: MBD-X11SSE-F
• Processor Per Node: LGA1151
  • Supports Intel Xeon E3-1200 v5 Series Processors
  • Supports 6th Generation Intel Core i3/ Pentium/ Celeron Processors
  • Supports up to 80W TDP
• Chipset Per Node: Intel C236
• Memory Per Node: 4x 288pin DDR4-2133 DIMM Slots, VLP, ECC, Unbuffered, Max Capacity of 64GB

• SATA Per Node: 2x SATA3 Ports
• Video Per Node: Aspeed AST2400 BMC Graphics
• LAN Per Node: 2x Intel i350 Gigabit Ethernet Controllers
• Drive Bays Per Node: 2x 3.5"/2.5" SATA3 HDDs per node; up to 24x 3.5"/2.5" drives total or 2x 2.5" NVMe + 2x 2.5" SATA3 drives per node; up to 48x 2.5" drives total
• Ports per Node: 1x USB 3.0 Port (Type A), 2x USB 2.0 Ports, 1x VGA Port, 2x RJ45 LAN Ports

• Form Factor: 3U Rackmount
• Power Supply: 2000W 80 PLUS Titanium Level (96%) High-efficiency Redundant Power Supplies
• System Cooling: 4x 9cm Heavy Duty Fans w/ Optimal Cooling Zone
• Color: Black
• Dimensions (WxDxH): 17.50 x 29.50 x 5.21 inch / 444.5 x 749.3 x 132.5 mm
• Weight: 95.0 lbs / 43.09 kg
• RoHS Compliant
