Specifications

• Mfr Part Number: SYS-1019S-M2
• Motherboard: Super X11SSZ-QF
• Processor: LGA1151
  • Supports 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
  • Supports up to 80W TDP
• Chipset: Intel Q170 Express
• Memory: 4x 288pin DDR4-2133/ 1866/ 1600 DIMM Slots, Support up to 64GB Non-ECC Unbuffered Memory
• Slots: 1x PCI-Express 3.0 x16 Slot
• SATA: 2x SATA3 Ports, Support RAID 0, 1
• Video: Integrated Aspeed AST2400 BMC Graphics and Intel HD Graphics 530
• Audio: RealTek ALC 888S High Definition Audio
• LAN: Intel PHY I219LM + Intel I210AT Gigabit Ethernet Controllers
• Drive Bays: 2x 2.5" Fixed SATA3 Drive Bays
• Ports: 2x USB 3.0 Ports (rear), 3x USB 2.0 Ports (2 rear, 1 Type A), 2x DisplayPorts, 1x DVI-I Port (from Intel HD Graphics), 1x VGA Port (from AST2400), 3x Independent Displays (from Processor Graphics), 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
• Form Factor: 1U Rackmount
• Power Supply: 400W 80 PLUS Platinum Certified Power Supply w/ PMBus and I2C
• System Cooling: 4x 40x 56 mm PWM Fans; 2x Fans for AOC Cooling
• Front Panel:
  • Buttons: Power On/Off, System Reset
  • LEDs: Power, Hard Drive Activity, 2x Network Activity, System Overheat
• Color: Black
• Dimensions (WxDxH): 17.2 x 16.9 x 1.7 inch / 437.0 x 429.0 x 43.0 mm
• Weight: 17.6 lbs / 8.0 kg
• RoHS Compliant
