Specifications

• Mfr Part Number: SYS-5018D-FN4T
• Motherboard: Super X10SDV-TLN4F
• Processor: Intel Xeon processor D-1541; Support up to 45W TDP

• Chipset: N/A
• Memory: 4x DDR4-2133/1600/1333 DIMM Slots, Support up to 128GB ECC/Load Reduced Memory or up to 64GB ECC/REG Memory
• Slots: 1x PCI-Express 3.0 x4 Slot (run at x16)
• SATA: 6x SATA3 Ports, SoC controller for SATA3 ports
• Video: Aspeed AST2400 BMC Graphics
• LAN: Dual 10GbE LAN Intel i350-AM2 Dual Port Gigabit Ethernet Controllers; 1x Realtek RTL8201N PHY (dedicated IPMI)
• Drive Bays: 2x 3.5" Hard Drive Bays
• Ports: 2x USB 3.0 Ports, 4x USB 2.0 Ports, 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 2x RJ45 LAN Ports, 2x RJ45 10GBase-T Ports, 1x RJ45 Dedicated IPMI LAN Port
• Form Factor: 1U Rackmount
• Power Supply: 200W 80 PLUS Gold Certified Low Noise AC-DC power supply with PFC
• System Cooling: Active CPU fan, 40mm chassis fan
• Front Panel:
  • Buttons: Power On/Off, System Reset
  • LEDs: Power, Hard Drive Activity, 2x Network Activity, System Overheat, Information
• Color: Black
• Dimensions (WxDxH): 17.2 x 9.8 x 1.7 inch / 437.0 x 249.0 x 43.0 mm
• Weight: 8.0 lbs / 3.62 kg
• RoHS Compliant
