Specifications

• Mfr Part Number: SYS-5019S-MR
• Motherboard: Super X11SSH-F
• Processor: Single Socket H4 LGA1151
  • Support Intel Xeon E3-1200 v6/ v5 Processors
  • Supports 7th/6th Generation Intel Core i3 Processors
  • Support up to 80W TDP
• Chipset: Intel C236
• Memory: 4x 288pin DDR4-2400/ 2133/ 1866/ 1600 MHz DIMM Slot, ECC, Unbuffered Memory, Max Capacity of 64GB
• Slots: 1x PCI-E 3.0 x8 (in x16) AOC slot
• SATA: 4x SATA3 Ports, Support RAID 0, 1, 5, 10
• Video: ASPEED AST2400 BMC Graphics

• LAN: Dual Intel I210-AT Gigabit Ethernet LAN Ports
• Drive Bays: 4x 3.5" Hot-swap SATA3 Drive Bays
• Backplane: SAS/SATA HDD Backplane (SAS support requires optional SAS controller)
• Ports: 4x USB 3.0 Ports (2 front, 2 rear), 2x USB 2.0 Ports (rear), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
• Form Factor: 1U Rackmount
• Power Supply: 400W 80 PLUS Platinum Level Certified Redundant Power Supplies w/ PMbus
• System Cooling: 4x (40x28mm) 4-pin PWM Cooling Fans
• Front Panel:
  • Buttons: Power On/Off, System Reset
  • LEDs: Power, Hard Drive Activity, 2x Network Activity, System Overheat
• Color: Black
• Dimensions (WxDxH): 17.2 x 19.8 x 1.7 inch / 437.0 x 503.0 x 43.0 mm
• Weight: 20.0 lbs / 9.1 kg
• RoHS Compliant
