Specifications

• Mfr Part Number: SYS-E200-8B
• Motherboard: Super X10SBA
• Processor: FCBGA1170
  • Intel Celeron J1900 Processor (2.0GHz, 2.42GHz Max Turbo, 2MB Cache, Quad-Core);  Supports 10W TDP
• Chipset: Intel J1900 System on Chip
• Memory: 2x 204pin DDR3-1333/ 1066 SODIMM Slots, Supports up to 8GB Non ECC Memory
• Slots: 1x Mini PCI-Express Slot, 1x mSATA Slot
• SATA: 4x SATA3 Ports, Support RAID 0, 1, 10; 2x SATA2 Ports
• Graphics: Intel HD Graphics
• LAN: Dual Intel I210-AT Gigabit Ethernet Controllers
• Drive Bays: 1x 2.5" HDD tray
• Ports: 1x USB 3.0 port, 1x USB 2.0 Ports, 1x Display Port, 1x HDMI Port, 1x VGA Port, 2x Independent Displays Ports, 2x RJ45 LAN Ports
• Form Factor: Mini-ITX
• Power Supply: 60W DC Power Adapter
• System Cooling: 1x 4cm cooling fan
• Front Panel:
  • Buttons: Power On/Off
  • LEDs: Power
• Color: Black
• Dimensions (WxDxH): 7.68 x 7.68 x 1.7 inch / 195.0 x 195.0 x 43.0 mm
• Weight: 3.86 lbs / 1.75 kg
• RoHS Compliant
