Specifications

• Mfr Part Number: X10DRI-T-B
• CPU: Dual LGA2011
  • Support Intel Xeon E5-2600 v4/v3 Family Processors
  • Support up to 22 Cores
  • Support up to 55MB Cache
  • QPI up to 9.6 GT/s
  • Support up to 145W TDP
• Chipset: Intel C612
• Memory: 16x 288pin DDR4-2400/ 2133/ 1866/ 1600 MHz DIMM Slots, Support up to 2TB ECC 3DS Load Reduced Memory or up to 1TB ECC/REG Memory
• Slots: 3x PCI-Express 3.0 x16 Slots, 3x PCI-Express 3.0 x8 Slots
• SATA: 10x SATA3 Ports, Support RAID 0, 1, 5, 10
• Video: Aspeed AST2400 BMC Graphics
• LAN: Intel X540 Dual Port 10GBase-T Gigabit Ethernet Controllers

• Ports: 5x USB 3.0 Ports (2 rear, 2 via header, 1 Type A), 6x USB 2.0 Ports (2 rear, 4 via headers), 1x VGA Port, 4x Serial Ports (1 rear, 1 via header, 2 Fast UART 16550), 2x RJ45 10GBase-T LAN Ports, 1x RJ45 Dedicated IPMI LAN Port

• Form Factor: EATX, 12.0 x 13.0 inch / 30.5 x 33.0 cm
• RoHS Compliant
