Specifications

• Mfr Part Number: SI-PEX50054
• Features:
  • Fully Compliant with PCI-e Base Specification, Revision 1.0a
  • PCI-e Multi Function Peripheral Controller with x1 Lane Interface
  • Support for D1, D2, D3hot and D3cold
  • Utilizes 100-Mhz Differential PCI-e Common Reference Clock
  • Supports PCI-e Power Management
  • Serial Port:
    • 2 16c450/550/Extended 550 Compatible UARTs
    • Supports RS232 Modes
    • Bi-directional Speeds from 50bps to 16Mbps/Port
    • Full Serial Modem Control
    • Supports Hardware, Software Flow Control
    • 5, 6, 7, 8 and 9-bit Serial Format Support
    • Support MODEM Modem Signals CTS, DSR, RI, DCD, the DTR, RTS, Convert RS232 Level
    • Even, Odd, None, Space & Mark Parity Supported
    • Custom BAUD Rates Supported with External Clock or by Programming Internal PLL
    • On Chip 256 Byte Depth FIFOs in Transmit, Receive Path of Each Serial Port
    • Support Remote Wakeup and Power management Features
    • Serial Port Transceiver Shutdown Support
    • Support Slow IrDA on all Serial Ports
    • IEEE1284 Parallel Port
    • Multi-mode IEEE 1284 Compliant COntroller (SPP, Nibble, Byte, PS/2, EPP, ECP)
    • Faster Data Rates up to 1.5Mbps for Parallel Port
• Chipset: WCH382 chipset
• Port: 2x Serial DB9 Ports, 1x Parallel Port
• Host Interface: PCI-Express x1
• Transfer Data Rates: 1.5 Mbps
• Software Requirement: Windows 8/ 7/ Vista/ XP/ ME/ 98SE, Microsoft Server 2003/ 2000 (32bit only), Linux Kernel 2.4 & 2.6 x86 OS only, Mac 10.4 & Above
• Hardware Requirement: Computer w/ PCI-Express Card Slot
• Package Contents:
  • PCI-e Multi I/O Card
  • Full Size Bracket for 2 Serial Ports
  • Full Size Bracket for 1 Parallel Port
  • Low Profile Bracket for 1 COM Port
  • Low Profile Bracket for 1 Parallel Port
  • User Manual
  • Driver Mini CD
