Specifications

• Mfr Part Number: RX1217SAS

• Storage:
  • Drive Bay: 12

  • Compatible Drive Type: 3.5" SAS HDD, 2.5" SAS HDD, 2.5" SAS SSD, 3.5" SATA HDD, 2.5" SATA SSD

  • Maximum Internal Raw Capacity: 120 TB (10 TB HDD x 12) (Capacity may vary by RAID types)

  • Hot Swappable Drive

  • RAID Management through Synology DSM

• External Ports: 2x SAS Ports (1x In, 1x Out)

• System Fan: 4x (60 x 60mm) Fans
• Easy Replacement System Fan
• Noise Level: 60.9 dBA
• Power:
  • Power Supply Unit / Adapter: 2x 500W

  • AC Input Power Voltage: 100V to 240V AC

  • Power Frequency: 50/60 Hz, Single Phase

  • Power Consumption: 132.7 W (Access), 89.3 W (HDD Hibernation)

  • British Thermal Unit: 452.79 BTU/hr (Access), 304.7 BTU/hr (HDD Hibernation)

  • Redundant Power Supply (for RP model)

• Applied Models: FS3017, RS18017xs+

• Certification: FCC Class A, CE Class A, BSMI Class A

• Dimensions (WxDxH): 482.0 x 724.0 x 88.0 mm

• Weight: 18.0 kg

• Packaging Content: Main Unit, Accessory Pack, 2x AC Power Cord, MiniSAS-HD Expansion Cable, Quick Installation Guide

• RoHS Compliant
